Lithium Battery Charger
Created with Pixso.

Automatic 20a Lifepo4 Battery Charger With Lcd Voltage Monitoring

Automatic 20a Lifepo4 Battery Charger With Lcd Voltage Monitoring

Brand Name: Sunchonglic
Model Number: FLA-10A+
MOQ: 100pcs
Price: US $3.98-27.89
Payment Terms: T/T
Supply Ability: 100000pcs/mon
Detail Information
Place of Origin:
China
Product Name:
Automatic 20A LiFePO4 Battery Charger With LCD Voltage Monitoring
Mechanical Shock And Vibration Resistance Level:
Complies With SAE J1378 Requirements
Maximum charging Current:
10A For 12V Battery;5.5A For 24V Battery
 Input Rated Frequency:
47-63Hz
Input Rated Voltage (AC):
150-250V
Packaging Details:
Paper Box
Product Description

Automatic 20A LiFePO4 Battery Charger with LCD Voltage Monitoring


>>>Product Description


What is feature of automatic 20a lifepo4 battery charger with lcd voltage monitoring?

  1. Wide Voltage Input Range:Supports an AC input of 150-250V, 47-63Hz, ensuring compatibility with various power grids worldwide.

  2. Automatic Battery Voltage Recognition:Automatically detects and adjusts the output voltage for 12V or 24V batteries, preventing incorrect connections.

  3. Multi-Protection Safety System:Features over-voltage protection (locks out if battery voltage >35V) and an intelligent fan that activates based on temperature and current.

  4. High Conversion Efficiency:Offers a full-load conversion efficiency of ≥84%, ensuring energy-saving operation and reduced heat generation.

  5. Wide Operating Temperature Range:Built to perform reliably in extreme environments, with an operating range from -40°C to +90°C.

  6. Rugged Construction:Designed to comply with SAE J1378 standards for shock and vibration resistance, making it suitable for demanding applications like vehicles and boats.


>>>Product Specifications


​Model FLA-10A+ FLA-20+
Input rated voltage (AC) 150-250V
 Input rated frequency 47-63Hz
Output voltage (DC) 14.6V, 29V
Battery voltage recognition method Automatically recognizes (prohibited to connect if battery voltage>35V)
Maximum charging current 10A for 12V battery;5.5A for 24V battery
Suitable battery voltage (DC) 12V, 24V
 Fan control Operates at temperatures ≥60° and stops at <50; operates at currents ≥1.5A and stops at =1.5A
Full load conversion efficiency ≥84%
 Operating temperature range -40℃ to +90°℃
Mechanical shock and vibration resistance level Complies with SAE J1378 requirements


>>>Our Factory

We are a manufacturer of Solar Energy Photovoltaic Products with many years history.
Our Factory produce Solar Power Inverter,AGM/GEL Lead Acid Battery Charger and Solar Charge Controller,etc.
Choosing Sunchonglic brand products are good choices.
More products information,please don't hesitate to contact us!


>>>Production Process


Automatic 20a Lifepo4 Battery Charger With Lcd Voltage Monitoring 0

>>>FAQ


Q1. Are you the factory manufacturer?
A1. With over two decades of expertise in solar energy photovoltaic solutions, we are the

original manufacturer and technology pioneer specializing in integrated solar products. Our

core innovations include hybrid solar inverters that combine inverter and controller

functionalities , power inverters, battery chargers, solar controllers, and comprehensive

solar systems.
Q2.How to select a suitable products?
A2.Tell us your demand, we will recommend a suitable one to you.
Q3. What is your payment methods?
A3. We accept T/T,Trade Assurance,etc.
Q4. What’s the price terms can you offer for us?
A4. We can accept EXW, FOB, CIF and so on.
Q5. Where is your main market for your products?
A5. Most of our Sunchonglic brand products are exported to Southeast Asia, Africa and
Mid East etc.


Our products are widely recognized and trusted by our clients and can meet continuously
changing economic and social needs.
We would sincerely welcome new and old customers from over the world to visit and
contact us for future business relationships and mutual success!
