PWM Solar Charge Controller
Created with Pixso.

20A Pwm Solar Charger Controller 5V 2A USB Output Manual 12 24 Volt Charge Controller

20A Pwm Solar Charger Controller 5V 2A USB Output Manual 12 24 Volt Charge Controller

Brand Name: Sunchonglic
Model Number: FT-D1220
MOQ: 100pcs
Price: US $3.98-27.89
Payment Terms: T/T
Supply Ability: 100000pcs/mon
Detail Information
Place of Origin:
China
Document:
Product Name:
12V 20A PWM Controllers Manual Pwm Solar Charger Controller 5V 2A USB
Low Power Recovery Voltage:
Default*12.6V(B1) Adjustable Range 11.5-12.6V
Working Temperatue :
-35℃~+60℃
Battery Type:
Lead Acid/AGM/GEL/Lithium Ion/Lithium Iron Phosphate Battery
Rated current:
20A
Standby Current:
<10mA
Packaging Details:
Paper Box
Highlight:

12V 20A PWM Solar Charge Controller

,

USB Output PWM Solar Charge Controller

,

Manual 12 24 Volt Charge Controller

Product Description

12V 20A  PWM Controllers Manual Pwm Solar Charger Controller 5V 2A USB



>>>Product Description


What is feature of 12V 20A  pwm controllers manual pwm solar charger controller 5V 2A usb?

1.5V 1A USB charging interface

2.Applicable for inductive loads(Applicable for Air conditioner)

3.Universal socket, suitable for all kinds of plugs

4.High-procision voltage stability technology

5.100% pure sine wave output waveform: designed for sensitive loads(Total Harmonic Distortion(THD)<3%

6.Multiple safe protections,including overload/overvoltage/low voltage/high temperature and output short circuit protection



20A Pwm Solar Charger Controller 5V 2A USB Output Manual 12 24 Volt Charge Controller 0




>>>Product Specifications


Model       FT-D1220
Rated current 20A
System Voltage 12V/24V system is only designed for lead-acid batteries with auto sense function
Solar PV input maximum voltage 12V system<25V; 24V system<50V
Battery Type B01=Lead Acid Battery 12V/24V auto sense
B02=Lithium-ion battery 3 series 3.7V=11.1V
B03=Lithium-ion phosphate battery 4 series 3.2V=12.8V
Charging voltage Default12.6V(B2)
adjustable range 11.5-12.6V
Low-voltage cut off voltage Default9V(B2)
adjustable range 8-11.5V
Low power recovery voltage Default10.5V(B2)
adjustable range 10-12V
External 12V battery recommended solar panel specifications 150-250W/18V
External 24V battery recommended solar panel specifications 300-400W/36V
Battery capacity recommended 12V/60-150Ah
24V/60-150Ah
Rated current of DC load output 12A
USB Output 5V/2A
Standby current <10mA
Working temperatue   -35℃~+60℃
Size / Weight   133x75x33mm/152g
Mark:* tagged voltage only corresponds to 12V solar system,if user use 24V system,please multiply by 2





>>>Our Factory


With over a decade of expertise in solar energy solutions, we are a leading manufacturer specializing in advanced photovoltaic products. Our facility produces high-performance solar inverters, AGM/GEL lead-acid battery chargers, and intelligent charge controllers, delivering comprehensive renewable energy solutions for residential and commercial applications . Backed by robust R&D capabilities and automated production lines, we prioritize quality control through professional inspections and real-world performance testing . Our global distribution network and dedicated technical team provide end-to-end support, from system design to post-installation maintenance .

For detailed specifications or customized solutions, contact our professional team to optimize your solar energy utilization!


>>>Production Process



20A Pwm Solar Charger Controller 5V 2A USB Output Manual 12 24 Volt Charge Controller 1

>>>FAQ


Q1. Are you the factory manufacturer?
A1. We are doing the Solar Energy Photovoltaic Products for over 20 years.
We are the original manufacturer and developer of advanced Solar Energy Photovoltaic
Product,including hybrid solar inverter, power inverter,battery chargers,solar controller,
and solar system,etc.
Q2.How to select a suitable products?
A2.Tell us your demand, we will recommend a suitable one to you.
Q3. What is your payment methods?
A3. We accept T/T,Trade Assurance,etc.
Q4. What’s the price terms can you offer for us?
A4. We can accept EXW, FOB, CIF and so on.
Q5. Where is your main market for your products?
A5. Most of our Sunchonglic brand products are exported to Southeast Asia, Africa and
Mid East etc.


Our products are widely recognized and trusted by our clients and can meet continuously
changing economic and social needs.
We would sincerely welcome new and old customers from over the world to visit and
contact us for future business relationships and mutual success!
