80A MPPT Solar Charge Controller with 180V DC Input and 97% Conversion Efficiency for 12V/24V/48V/60V Batteries

80A MPPT Solar Charge Controller with 180V DC Input and 97% Conversion Efficiency for 12V/24V/48V/60V Batteries

Brand Name:	Sunchonglic
Model Number:	MPPT-80A(12V-60V)
MOQ:	100pcs
Price:	US $11.15-178.34
Payment Terms:	T/T
Supply Ability:	100000pcs/mon

Detail Information

Product Description

Detail Information

Place of Origin:

China

Product Name:

Solar Mppt Charger 12V 24V 48V 60V 80A Solar Mppt Charge Controller

PV Maximum Open Circuit Input Voltage:

0-180V

Charging Mode:

MPPT Automatic Maximum Power Tracking

Altiude:

0~3000m

Lead Acid:

（12V/24V/48V/60VAuto+Adjustable 12V/24V/48V/60V)

Protection Level:

IP 21

Packaging Details:

Paper Box

Highlight:

Compact MPPT Solar Charge Controller

Portable MPPT Solar Charge Controller

Compact 12 Volt Solar Charge Controller

Product Description

Compact MPPT Solar Charge Controller

Professional 12V/24V/48V/60V 80A MPPT solar charge controller with advanced power tracking technology for optimal energy utilization.

Key Features

Compatible with 12V/24V/48V/60V battery systems
Maximum MPPT PV array operating voltage: 180V DC
Advanced maximum power point tracking technology with up to 97% conversion efficiency
Rapid I-V curve scanning for efficient maximum power point tracking
Supports multiple battery types: sealed, colloidal, open-type lead-acid, and lithium series
Comprehensive protection: overcharge, overdischarge, overload, and short circuit

Technical Specifications

Model	60A/80A
Charging Mode	MPPT automatic maximum power tracking
Charging Method	MPPT tracks maximum power, fast charge, balanced charge, and float charge
Battery Types	Lead Acid: 12V/24V/48V/60V Auto+Adjustable Gel: 12V/24V/48V/60V LifePo4: Single voltage 3.2* number of strings (2-45 strings adjustable) Li-ion: Single voltage 3.7* number of strings (2-45 strings adjustable) USER: Adjustable limit voltage for equal charge, float charge and DC discharge: 8V-170V
Lithium Battery Activation	With photovoltaic input, there is charging voltage (activate lithium battery), can be used without battery DC output
PV Maximum Open Circuit Input Voltage	0-180V
Charging Current	0-60A / 0-80A (adjustable)
Start Charging	PV voltage is greater than +3V of battery voltage (low current charging on rainy days)
Direct Charging Current Output	DC continuous output 40A
Temperature Compensation	Automatically compensates charging voltage and current based on battery temperature to extend battery life
Working Temperature	-20℃ to 40℃
Protection Level	IP21
Altitude	0-3000m
Product Size	218x265x100mm

Manufacturing Excellence

We are a seasoned producer of solar photovoltaic products with over 20 years of experience. Our facility specializes in manufacturing solar inverters, AGM/GEL lead-acid battery chargers, and solar charge controllers. Choosing Sunchonglic brand products ensures quality and reliability.

Frequently Asked Questions

Are you the factory manufacturer?

We have been manufacturing Solar Energy Photovoltaic Products for over 20 years. We are the original manufacturer and developer of advanced solar energy products including hybrid solar inverters, power inverters, battery chargers, solar controllers, and complete solar systems.

How to select a suitable product?

Tell us your requirements and we will recommend the most suitable product for your needs.

What are your payment methods?

We accept T/T, Trade Assurance, and other secure payment options.

What price terms can you offer?

We can accommodate EXW, FOB, CIF, and other international trade terms.

Where is your main market?

Our Sunchonglic brand products are primarily exported to Southeast Asia, Africa, and the Middle East.

Our product range has gained international acclaim and confidence, adeptly responding to changing economic and societal needs. We warmly welcome both prospective and current global partners to join forces, nurturing partnerships that propel mutual prosperity!
