72 Volt MPPT Solar Charge Controller with Overheating Protection and Scalable Versatile Design

72 Volt MPPT Solar Charge Controller with Overheating Protection and Scalable Versatile Design

Brand Name:	Sunchonglic
Model Number:	MPPT-50A(12V-96V)
MOQ:	100pcs
Price:	US $11.15-178.34
Payment Terms:	T/T
Supply Ability:	100000pcs/mon

Detail Information

Product Description

Detail Information

Place of Origin:

China

Product Name:

Hot Selling Mppt Charger Controller 12V 24V 36V 48V 60V 72V 96V 30A 40A 60A MPPT Solar Charge Controller

Working Environment Temperature:

-20℃-40℃

Charging Mode:

MPPT Automatic Maximum Power Tracking

The Charging Current Is Adjustable:

0-30A 0-40A 0-50A 0-60A 0-100A 0-120A

Lead Acid:

（12V/24V/48V/60VAuto+Adjustable 12V/24V/48V/60V)

PV Maximum Open Circuit Input Voltage:

0-230V

Packaging Details:

Paper Box

Highlight:

Versatile 72 Volt Solar Charge Controller

Scalable 72 Volt Solar Charge Controller

Overheating Protection 72v solar charge controller

Product Description

Overheating Protection 72 Volt Solar Charge Controller

Scalable and versatile MPPT solar charge controller supporting 12V to 96V systems with advanced protection features.

Product Features

Manually adjustable charging current for optimal performance
Multiple charging and discharging protection systems
Compatible with 12V/24V/36V/48V/60V/72V/84V/96V DC systems
Maximum PV array open circuit voltage: 230V DC
Supports up to 96V lead acid batteries
Compatible with up to 45 cells LiFePO4 batteries

Technical Specifications

Model	30A/40A	50A/60A	100A/200A
Charging Mode	MPPT automatic maximum power tracking
Charging Method	MPPT tracks maximum power, fast charge, balanced charge, and float charge
Battery Type	Lead Acid: 12V/24V/36V/48V/96V Auto+Adjustable Gel: 12V/24V/36V/48V/60V/72V/84V/96V LifePo4: Single voltage 3.2* numbers of strings (2-45 strings adjustable) Li-ion: Single voltage 3.7* numbers of strings (2-45 strings adjustable) USER: Adjustable limit voltage for equal charge, float charge and DC discharge: 8V-170V
Lithium Battery Activation	With photovoltaic input, there is charging voltage (activate lithium battery), can be used without battery DC output
PV Maximum Open Circuit Input Voltage	0-230V
Charging Current Adjustable	0-30A / 0-40A	0-50A / 0-60A	0-100A / 0-120A
Start Charging	PV voltage is greater than +3V of battery voltage (low current charging on rainy days)
Direct Charging Current Output	DC continuous output 25A	DC continuous output 60A	DC continuous output 100A
Temperature Compensation	Automatically compensates charging voltage and current based on battery temperature to extend battery life
Display & Communication	LCD display with touch button: generating capacity/photovoltaic voltage/battery voltage/charging current/power/operation status Chinese and English display Settings: battery type, charging current, return to factory 8-pin RS485 communication interface (operation status and setting can be queried)
Working Environment Temperature	-20℃ to 40℃
Protection Level	IP21
Altitude	0-3000m
Product Size	202x215x100mm	218x265x100mm	/

Manufacturing Excellence

With over 20 years of expertise in solar PV technology, our factory specializes in manufacturing high-quality solar inverters, AGM/GEL battery chargers, and advanced solar controllers. Choosing Sunchonglic products ensures reliable performance and innovation.

Production Process

Frequently Asked Questions

Are you the factory manufacturer?

With over 20 years of experience, we lead as an OEM in innovative solar PV technology, offering hybrid inverters, power conversion equipment, charge controllers, energy storage, and complete solar kits, all designed for maximum efficiency.

How to select a suitable product?

Tell us your requirements, and we will recommend the most suitable solution for your needs.

What are your payment methods?

We accept T/T, Trade Assurance, and other secure payment options.

What price terms can you offer?

We can accommodate EXW, FOB, CIF, and other international trade terms.

Where is your main market?

Our Sunchonglic brand products are primarily exported to Southeast Asia, Africa, and the Middle East regions.

Our diverse product portfolio has earned global recognition and trust, skillfully adapting to evolving economic and societal demands. We invite both new and established international partners to collaborate with us, fostering alliances that drive shared success and prosperity!
