3000W Solar Power Inverter with MPPT DC to AC Converter 12V to 220V Modified Sine Wave Output

3000W Solar Power Inverter with MPPT DC to AC Converter 12V to 220V Modified Sine Wave Output

Brand Name:	Sunchonglic
Model Number:	SUS-3000A+MPPT
MOQ:	5pcs
Price:	US $53.85 - 60.00
Payment Terms:	T/T
Supply Ability:	100000pcs/mon

Detail Information

Product Description

Detail Information

Place of Origin:

China

Product Name:

3000W Solar Power Inverter With MPPT DC To AC Converter 12V To 220V Modified Sine Wave Output

Maximum Continuous Power:

1500W

Conversion Efficiency:

>90%

Featured Solar Panel Specifications:

100~200W/36V∗2

The Built-in Controller:

25A~30A

Peak Power:

4000W

Packaging Details:

Paper Box

Highlight:

3000w solar power inverter

MPPT DC to AC converter

12v to 220v modified sine wave inverter

Product Description

3000W Solar Power Inverter with MPPT DC to AC Converter

12V to 220V Modified Sine Wave Output for reliable solar energy conversion

Product Features

Modular inverter unit design with external battery for enhanced portability and adaptability
Comprehensive residential energy systems from 100W to 1000W capacity
AC output: 220V for computers, televisions, fans, and household appliances
DC output: 12V(24V) and 5V options for LED lighting, surveillance equipment, and mobile charging
Large high-resolution LED display interface for clear system monitoring
Modified sine wave output with capacities of 12V 1000VA or 1500VA

Technical Specifications

Model	SUS-3000A+MPPT
Built-in Controller	25A~30A
Solar Panel Specifications	100~200W/36V∗2
External Battery	12V 100Ah~150Ah
Output Voltage	AC 220V±5%
Maximum Continuous Power	1500W
Peak Power	4000W
No Load Current	<0.5A
DC Input Voltage	DC9.7V~15.5V
Output Frequency	50Hz±3Hz
Conversion Efficiency	>90%
High Pressure Cut Off	15V±0.5V
Low Voltage Alarm	11.2V±0.3V
Low Cut	10V±0.3V
Protection Features	Overload, short circuit protection
Output Waveform	Modified sine wave
Cooling System	Fan cooled
Operating Temperature	-20℃~+70℃
Relative Humidity	<90%RH
Dimensions	230x127x67mm
Weight	1.5kg

Manufacturing Expertise

With over 20 years of industry experience, we specialize in manufacturing solar energy photovoltaic products. Our factory produces a comprehensive range of equipment including solar power inverters, AGM/GEL lead-acid battery chargers, and solar charge controllers. Choosing Sunchonglic brand products ensures reliable and efficient performance for all your solar energy needs.

Production Process

Frequently Asked Questions

Are you the factory manufacturer?

We have been manufacturing Solar Energy Photovoltaic Products for over 20 years. We are the original manufacturer and developer of advanced solar energy products including hybrid solar inverters, power inverters, battery chargers, solar controllers, and complete solar systems.

How to select a suitable product?

Tell us your specific requirements and we will recommend the most suitable solution for your needs.

What are your payment methods?

We accept T/T, Trade Assurance, and other secure payment options.

What price terms can you offer?

We can accommodate EXW, FOB, CIF and various other international trade terms.

Where is your main market?

Our Sunchonglic brand products are primarily exported to Southeast Asia, Africa, and the Middle East regions.

Our products are widely recognized and trusted by clients worldwide, meeting continuously evolving economic and social needs. We sincerely welcome both new and existing customers to contact us for future business relationships and mutual success!
