600W 182-Cell Solar Panel | 144tb & 1500V DC for Peak Efficiency

600W 182-Cell Solar Panel | 144tb & 1500V DC for Peak Efficiency

Brand Name: Sunchonglic
Model Number: SUN 585Wp
MOQ: 20pcs
Price: Negotiate
Payment Terms: ,T/T
Supply Ability: 100000pcs/mon
Detail Information
Place of Origin:
China
Product Name:
600W 182-Cell Solar Panel 144tb & 1500V DC For Peak Efficiency
Refer. Bifacial Factor:
80±5%
Temperature Coefficient Lsc:
0.045%/℃
NOCT:
45℃±2℃
Max. Power Voltage-Vmpp(V):
45.06
Power Tolerance:
0~+3%
Packaging Details:
Paper Box
Product Description

600W 182-Cell Solar Panel 144tb & 1500V DC for Peak Efficiency


>>>Product Description


What is feature of  585wp solar panel 182m / 144tb 1500v dc  ?

  1. Light Redirecting Film: Ronma TOPCon modules incorporate gap-based light guidance film technology to boost bifacial performance and module durability, while also elevating overall power generation efficiency.

  2. Non-Destructive Cutting: Ronma applies non-destructive cutting (NDC) methods that deliver clean incision edges and prevent mechanical stress, maintaining cell structural integrity and unimpeded current transmission.

  3. Junction Box Laser Welding Technology: Through high-precision laser welding with exact positioning control, Ronma achieves superior junction box bonding, enhancing both safety and operational consistency of the modules.

  4. Higher Power Output: These modules typically see a power gain ranging from 5% to 25%, leading to markedly reduced levelized energy costs and improved investment returns, backed by a positive power tolerance warranty of 0–5W.

  5. PID Resistance: Refined manufacturing and material management deliver outstanding resistance to potential-induced degradation, supporting sustained module performance over time.

  6. Environmental Durability: Ronma modules carry TUV NORD certification for high resistance to salt mist and ammonia, attesting to their durability in harsh environmental settings.



600W 182-Cell Solar Panel | 144tb & 1500V DC for Peak Efficiency 0


>>>Product Specifications


ELECTRICAL CHARACTERISTICS (STC*)
Rated Power in Watts-Pmax(Wp) 560 565 570 575 580 585 590 595 600
Open Circuit Voltage-VocV) 52.45 52.61 5277 52.93 53.09 53.25 53.41 53.57 53.73
Short Circuit Current-Isc(A) 13.47 13.55 13.62 13.69 13.76 13.83 13.89 13.95 14.01
Max. Power Voltage-Vmpp(V) 44.12 44.26 44.39 4.61 44.84 45.06 45.28 45.5 45.72
Max, Power Current-Impp(A) 12.71 12.79 1285 12.9 12.95 13.00 13.06 13.12 13.18
Module Efficiency(%) 21.67 21.86 2206 22.25 22.44 22.6 22.8 23.02 23.22
Maximum system voltage 1500V DC
Fuse Rating(A) 30
Temperature coefficient Pmax -0.29%/℃
Temperature coefficient lsc 0.045%/℃
Temperature coefficient Voc -0.25%/℃
Refer. Bifacial Factor 80±5%
*STC:Irradiance 1000W/m2,module temperature 25,AM=1.5

WORKING CHARACTERISTICS (NOCT*)
Rated Power in Watts-Pmax(Wp) 421 425 429 432 436 440
Open Circuit Voltage-Voc(V) 48.13 48.32 48.51 48.7 48.89 49.08
Short Circuit Current-lsc(A) 11.41 11.46 11.5 11.55 11.6 11.65
Max. Power Voltage-Vmpp(V) 39.39 39.52 39.65 39.78 39.87 40.00
Max. Power Current-Impp(A) 10.69 10.75 10.81 10.87 10.94 11.01
Power tolerance 0~+3%
NOCT 45±2
OperatingTemperature                                   40~85
*NOCT:lrradiance 800W/m2,ambient temperature 20, wind speed 1m/s

Electrical characteristics with different rear side power gain
  Pmax/W Voc/V lsc/A Vmpp/V Impp/A
5% 630 53.73 14.71 45.72 13.84

The additional gain from the rear side compared to the power of the front side at the standard test condition.

It depends on mounting (structure, height, tilt angle etc.) and albedo of the ground.


MECHANICAL CHARACTERISTICS
Number of cells 144pcs Type of frame Anodized Aluminum Alloy
Type of cell N-TOPCon Mono Size of module(mm) 2279×1134×35
Thickness of glass(mm) 2.0 Weight(kg) 32
Junction box IP68,1500V DC, 3 Diodes Cables/connectors 4.0mm2, MC4 compatible
Length of Cable +300mm/-200mm Length can be customized    (connectorincluded)

PACKAGING CONFIGURATION
Height of Modules (mm) 35 30
Number of Modules Per Pallet 31 36
Packaging Box Dimensions (lXw×h) (mm) 2300×1120×1260 2300×1120×1260
Box Gross Weight (kg) 1020 1180
Number of Modules Per 40ft (HQ) Container 620 720
Number of Pallets Per 40ft (HQ) Container 20 20
