1000W Peak Power Modified Sine Wave Inverter with Built-in 20A PWM Solar Controller for 12V DC to 220V AC Conversion

Name: 1000W Peak Power Modified Sine Wave Inverter with Built-in 20A PWM Solar Controller for 12V DC to 220V AC Conversion
Brand: Foshan Suntway Technology Co. Ltd.
SKU: SUS-1000AL+PWM
Price: 56.85 USD
Availability: InStock

Brand Name:	Sunchonglic
Model Number:	SUS-1000AL+PWM
MOQ:	5pcs
Price:	US $53.85 - 60.00
Payment Terms:	T/T
Supply Ability:	100000pcs/mon

Detail Information

Product Description

Detail Information

Place of Origin:

China

Product Name:

SUS-1000AL+PWM 1000W Modified Sine Wave Solar Inverter All-in-one With 20A PWM Solar Controller 12V

Output Waveform:

Modified Sine Waveform Output

Overload/short Circuit Protection:

Yes

Output Frequency:

50Hz±3Hz

Relative Humidity:

<90%RH

Low Voltage Alarm:

11.2V±0.3V

Packaging Details:

Paper Box

Highlight:

1000W Peak Power Modified Sine Wave Inverter

Built-in 20A PWM Solar Controller Solar Power Inverter

12V DC to 220V AC Conversion All-in-One Inverter

Product Description

SUS-1000AL+PWM 1000W Modified Sine Wave Solar Inverter All-in-one With 20A PWM Solar Controller 12V

The SUS-1000AL+PWM is an integrated all-in-one solar inverter combining modified sine wave inverter and 20A PWM solar charge controller, specially designed for 12V off-grid home solar power systems. It converts 12V DC battery power into standard 220V AC household electricity while supporting direct charging of 12V lead-acid batteries by solar panels, significantly reducing purchase costs and installation space for small solar projects.

Key Features

Model: SUS-1000AL+PWM, 12V battery system with built-in 20A PWM solar charge controller
Modified sine wave output with rated continuous power 600W and peak power 1000W
DC12V to AC220V conversion with PV input range: 14V~60V
Compatible with 100~200W 18V solar panels & 12V 100-150Ah batteries
Built-in DC12V output port & USB output 5.0±0.3V for small electronic devices
Comprehensive safety protection including battery reverse protection, overload, and short-circuit protection
Large LED display screen for real-time working status monitoring
Fan cooling mode with conversion efficiency >90% and low no-load current <0.5A
Operating temperature: -20℃ to +70℃ with relative humidity <90%RH

Technical Specifications

Model	SUS-1000AL+PWM
Built-in Controller	15A
Solar Panel Specifications	500-600W/60V
External Battery	12V 100Ah~150Ah
USB Output Voltage	5.0 +/-0.3V
Inverter Output Voltage	AC 220V +/-5%
Maximum Continuous Power	600W
Peak Power	1000W
No Load Current	<0.5A
DC Input Voltage	DC 9.7V~15.5V
Output Frequency	50 +/-3Hz
Conversion Efficiency	>90%
High Pressure Cut Off	15V +/-0.5V
Low Voltage Alarm	11.2V +/-0.3V
Low Cut	10V +/-0.3V
Protection Features	Overload and short circuit protection
Output Waveform	Fixed wave
Cooling System	Fan cooled
Operating Temperature	-20℃ to +70℃
Relative Humidity	<90% RH

Manufacturing Excellence

With over a decade of expertise in solar energy solutions, we are a leading manufacturer specializing in photovoltaic products. Our facility produces high-performance solar power inverters, AGM/GEL lead-acid battery chargers, and solar charge controllers, offering comprehensive solutions for residential and commercial applications. Sunchonglic products deliver cutting-edge technology with a proven track record of reliability.

Production Process

Frequently Asked Questions

Are you the factory manufacturer?

We have been manufacturing Solar Energy Photovoltaic Products for over 20 years. We are the original manufacturer and developer of advanced Solar Energy Photovoltaic Products, including hybrid solar inverters, power inverters, battery chargers, solar controllers, and complete solar systems.

How to select a suitable product?

Tell us your requirements, and we will recommend the most suitable product for your needs.

What are your payment methods?

We accept T/T, Trade Assurance, and other secure payment options.

What price terms can you offer?

We can accommodate EXW, FOB, CIF, and various other international trade terms.

Where is your main market?

Our Sunchonglic brand products are primarily exported to Southeast Asia, Africa, and the Middle East regions.

Our products are widely recognized and trusted by our clients and can meet continuously changing economic and social needs. We would sincerely welcome new and old customers from around the world to visit and contact us for future business relationships and mutual success!

For detailed product specifications, please contact our professional team for prompt assistance!
