10A 24 Volt LCD Display PWM Solar Charge Controller with Manual Settings and USB Output

10A 24 Volt LCD Display PWM Solar Charge Controller with Manual Settings and USB Output

Brand Name:	Sunchonglic
Model Number:	FT-D1210
MOQ:	100pcs
Price:	US $3.98-27.89
Payment Terms:	T/T
Supply Ability:	100000pcs/mon

Detail Information

Product Description

Detail Information

Place of Origin:

China

Product Name:

LCD Display PWM Controller 12V 24V 10A 10amp Manual Pwm Solar Charge Controller

Battery Type:

Lead Acid/AGM/GEL/Lithium Ion/Lithium Iron Phosphate Battery

Working Temperatue :

-35℃~+60℃

Solar PV Input Maximum voltage:

12V System<25V; 24V System<50V

Low Power Recovery Voltage:

Default*12.6V(B1) Adjustable Range 11.5-12.6V

USB Output:

5V/2A

Packaging Details:

Paper Box

Highlight:

10amp Manual PWM Solar Charge Controller

Compact Manual PWM Solar Charge Controller

LCD Display 24 Volt Charge Controller

Product Description

LCD Display PWM Solar Charge Controller 12V/24V 10A

Professional 10amp manual PWM solar charge controller with LCD display, designed for efficient solar power management in 12V and 24V systems.

Key Features

5V/2A USB charging interface for device connectivity
Compatible with multiple battery types: Lead Acid, Lithium Ion, and Lithium Iron Phosphate
Large-screen LCD display for clear system monitoring
Complete three-phase PWM charge management (Constant Current, Constant Voltage, Floating Charge)
Comprehensive protection systems: Overcurrent, Short Circuit, Open Circuit, and Battery Reverse Protection
Power-cut memory function retains user settings automatically

Technical Specifications

Model	FT-D1210
Rated Current	10A
System Voltage	12V/24V auto-sensing (lead-acid batteries)
Solar PV Input Max Voltage	12V system <25V; 24V system <50V
Battery Types	B01=Lead Acid (12V/24V auto sense) B02=Lithium-ion (3 series 3.7V=11.1V) B03=Lithium iron phosphate (4 series 3.2V=12.8V)
Charging Voltage	Default: 14.3V (B1) Adjustable range: 13.7-14.6V
Low-voltage Cut Off	Default: 10.7V (B1) Adjustable range: 8-11.5V
Low Power Recovery Voltage	Default: 12.6V (B1) Adjustable range: 11.5-12.6V
Recommended Solar Panel	12V: 100-150W/18V 24V: 150-200W/36V
Recommended Battery Capacity	12V/24-80Ah 24V/24-80Ah
DC Load Output	12A
USB Output	5V/2A
Standby Current	<10mA
Operating Temperature	-35℃ to +60℃
Dimensions / Weight	1337533mm / 152g

* Tagged voltage values correspond to 12V solar systems. For 24V systems, multiply by 2.

Manufacturer Information

We are an established manufacturer with over 20 years of experience in solar energy photovoltaic products. Our product range includes solar power inverters, AGM/GEL lead acid battery chargers, solar charge controllers, and complete solar systems.

Frequently Asked Questions

Are you the factory manufacturer?

Yes, we have been manufacturing solar energy photovoltaic products for over 20 years. We are the original manufacturer and developer of advanced solar products including hybrid solar inverters, power inverters, battery chargers, solar controllers, and complete solar systems.

How to select a suitable product?

Tell us your specific requirements and we will recommend the most suitable product for your application.

What are your payment methods?

We accept T/T, Trade Assurance, and other secure payment options.

What price terms can you offer?

We can accommodate various price terms including EXW, FOB, CIF, and others.

Where is your main market?

Our Sunchonglic brand products are exported worldwide, with strong presence in Southeast Asia, Africa, and the Middle East.

Our products are widely recognized and trusted by clients worldwide, meeting continuously changing economic and social needs. We welcome both new and existing customers to contact us for future business relationships and mutual success!
