3000va 2100w UPS MPPT Solar Hybrid Inverter 24v 60A Low Frequency With AC Charger

3000va 2100w UPS MPPT Solar Hybrid Inverter 24v 60A Low Frequency With AC Charger

Brand Name: Sunchonglic
Model Number: FMP-3000B
MOQ: 5pcs
Price: US $83.8-288.61
Payment Terms: T/T
Supply Ability: 100000pcs/mon
Detail Information
Place of Origin:
China
Document:
Product Name:
24v 3000va 2100w Low Frequency UPS Pure Sine Wave 60A MPPT Solar Hybrid Inverter With AC Charger
Charge Modes:
3 Stage;bulk,boost,float
PV Array Input Voltage:
30V-180V
Voltage Range:
AC160-260V
Operating Humidity:
10-90%
Solar Charging Current:
60A
Packaging Details:
Paper Box
Highlight:

24v 60A MPPT Solar Hybrid Inverter

,

3000va 2100w MPPT Solar Hybrid Inverter

,

Low Frequency 3kva hybrid inverter

Product Description

24v 3000va 2100w Low Frequency UPS Pure Sine Wave 60A MPPT Solar Hybrid Inverter With AC Charger

>>>Product Description


What is feature of 24v 3000va 2100w low frequency UPS pure sine wave 60A MPPT solar hybrid inverter with AC charger ?

1.12V 1000va UPS pure sine wave MPPT inverter

2.Pure sine waveform output with built-in transformer and voltage stabilizer(Specially designed for start up inductive loads)

3.Support 3 working modes: Mains priority, Battery priority, PV priority

4.Pure Sine Waveform Output

5. 3 times start-up peak power of resisting voltaic impingement, excellent loading capability

6. Includes a built-in Lithium battery activation function







3000va 2100w UPS MPPT Solar Hybrid Inverter 24v 60A Low Frequency With AC Charger 0


>>>Product Specifications



Specification Model 3000VA
Power 2100W
Input  Voltage range AC160-260V
Frequency range 50Hz/60Hz
Output AC Voltage Regulation
(Batt.Mode)
AC220V±25V
Frequency range
(Batt.Mode)
50Hz/60Hz
Waveform Pure Sine Wave
Battery Battery Type(external) 24V
Rated battery voltage 24VDC(20-32V)
Charge Modes 3 stage;bulk,boost,float
Charging current DC20A
Protection Overload,Overheat,Output high/low voltage,Battery low voltage,Short-circuit,Over-charge,Over-discharge
General characteristics Switch time 10ms
Operating Humidity 10-90%
Operating Temperature 0℃+40℃
Class Protection IP20
Dimension DxWxH(mm)

440x228x200
465x320x200
MPPT(Optional) PV array Input Voltage 30V-180V
Solar charging current 60A





>>>Our Factory


We specialize in manufacturing solar photovoltaic products and have a rich history in the industry. Our Factory produce Solar Power Inverter,AGM/GEL Lead Acid Battery Charger and Solar Charge Controller,etc.Choosing Sunchonglic brand products are good choices.
For more information,feel free to contact us at any time!


>>>Production Process



3000va 2100w UPS MPPT Solar Hybrid Inverter 24v 60A Low Frequency With AC Charger 1

>>>FAQ


Q1. Are you the factory manufacturer?
A1. We are doing the Solar Energy Photovoltaic Products for over 20 years.
We are the original manufacturer and developer of advanced Solar Energy Photovoltaic
Product,including hybrid solar inverter, power inverter,battery chargers,solar controller,
and solar system,etc.
Q2.How to select a suitable products?
A2.Tell us your demand, we will recommend a suitable one to you.
Q3. What is your payment methods?
A3. We accept T/T and Trade Assurance,etc.
Q4. What’s the price terms can you offer for us?
A4. We can accept EXW, FOB, CIF and so on.
Q5. Where is your main market for your products?
A5. Most of our Sunchonglic brand products are exported to Southeast Asia, Africa and
Mid East etc.


Our products are widely recognized and trusted by our customers for meeting the evolving economic and social needs.We will sincerely welcome new and old customers from around the world to visit and contact us to establish futrue business relationships and achieve mutual success!
