30A Rated Current PWM Solar Charge Controller with LCD Display and Three Phase PWM Technology

30A Rated Current PWM Solar Charge Controller with LCD Display and Three Phase PWM Technology

Brand Name:	Sunchonglic
Model Number:	FT-S1230
MOQ:	100pcs
Price:	US $3.98-27.89
Payment Terms:	T/T
Supply Ability:	100000pcs/mon

Detail Information

Product Description

Detail Information

Place of Origin:

China

Product Name:

12V 24V 30A LCD Display Three Phase PWM Solar Charge Controller 5V / 2A USB

Maximum input Voltage:

<50V

System Voltage:

12V/24V

Rated current:

30A

Low-voltage Cut Off Voltage:

10V(B03)

Size / Weight :

125*86*34mm/200g

Packaging Details:

Paper Box

Highlight:

Portable 30 Amp Solar Charge Controller

3P 30 Amp Solar Charge Controller

Portable 12v Pwm Solar Charge Controller

Product Description

12V 24V 30 Amp Solar Charge Controller with LCD Display

Advanced PWM solar charge controller featuring LCD display, 5V/2A USB output, and comprehensive battery management for efficient solar power systems.

Product Features

Compatible with three battery types: Lead Acid, Lithium Ion, and Lithium Iron Phosphate
Power-cut memory function automatically retains user settings
Large-screen LCD display for clear system monitoring
Three-phase PWM charge management (Constant Current, Constant Voltage, Floating Charge)
Multiple protection systems: Overcurrent, Short Circuit, Open Circuit, and Battery Reverse Protection
Double MOS tube anti-reverse circuit prevents nighttime power loss

Technical Specifications

Model	FT-S1230
System Voltage	12V/24V
Maximum Input Voltage	<50V
Rated Current	30A
Recommended Solar Panel (12V)	300-450W/18V
Recommended Solar Panel (24V)	300-450W/36V
External Battery	12V 100-150Ah / 24V 100-150Ah
Battery Types	B01=Lead Acid 12V, B02=Li-ion 11.1V, B03=LiFePO4 12.8V
Charging Voltage (B03)	14.6V
Low-Voltage Cut Off (B03)	10V
Low Power Recovery (B03)	12V
USB Output	5V/2A
Standby Current	<10mA
Working Temperature	-35℃ to +60℃
Size / Weight	1258634mm / 200g

Manufacturing Excellence

With over 20 years of expertise in solar photovoltaic innovation, we engineer high-efficiency solar power inverters using cutting-edge production technologies. Our robust R&D team and international certifications (ISO, CE) ensure reliable renewable energy solutions for global markets.

Frequently Asked Questions

Are you the factory manufacturer?

We are the original manufacturer and developer of advanced Solar Energy Photovoltaic Products with over 20 years of experience, including hybrid solar inverters, power inverters, battery chargers, solar controllers, and complete solar systems.

How to select a suitable product?

Tell us your requirements and we will recommend the most suitable product for your application.

What are your payment methods?

We accept T/T, Trade Assurance, and other secure payment options.

What price terms can you offer?

We offer EXW, FOB, CIF and other international trade terms.

Where is your main market?

Our Sunchonglic brand products are exported worldwide, with strong presence in Southeast Asia, Africa, and the Middle East.

Our products are widely recognized and trusted by clients worldwide, meeting continuously changing economic and social needs. We welcome new and existing customers to contact us for future business relationships and mutual success!
