1.2kW Pure Sine Wave Solar Inverter with MPPT Dual AC / PV Charging & UPS Function

Brand Name:	Sunchonglic
Model Number:	SUNer-D 1200-12
MOQ:	100pcs
Price:	US $9.09-67.82
Payment Terms:	T/T
Supply Ability:	100000pcs/mon

Detail Information

Product Description

Detail Information

Place of Origin:

China

Product Name:

1.2kW Pure Sine Wave Solar Inverter With MPPT Dual AC / PV Charging & UPS Function

Surge Power (kVA):

2.4

Voltage (VAC):

208/220/230/240

Frequency (Hz):

50/60(Auto Adaptive)

Communication:

RS485/RS232

Ingress Protection:

IP21

Packaging Details:

Paper Box

Product Description

1.2kW Pure Sine Wave Solar Inverter with MPPT Dual AC / PV Charging & UPS Function

>>>Product Description

What is feature of 1.2kw pure sine wave solar inverter with mppt dual ac / pv charging & ups function?

1.LCD Display
2.Wide MPPT Range 18-125V
3.Power Factor 1.0
4.Built-in 60A Solar Charger
5.Pure Sine Wave
6.All around protection

1.2kW Pure Sine Wave Solar Inverter with MPPT Dual AC / PV Charging & UPS Function 0

>>>Product Specifications

Model	SUN-D1200-12
AC Input
Rated Input Voltage (VAC)	208/220/230/240; L+N+PE
Voltage Range (VAC)	90~280±3 (normal mode); 170~280±3 (UPS mode)
Frequency (Hz)	50/60(Auto Adaptive)
AC Output
Rated Capacity (kW)	1.2
Surge Power (kVA)	2.4
Voltage (VAC)	208/220/230/240
Power Factor (PF)	1
Frequency	50/60Hz±0.1%
Switch Time (ms)	10
Wave Form	Pure Sine Wave
Overload Capacity (Battery Mode)	60s@102%~110%;10s@110%~130%;3s@130%~150%;0.2s@>150%;
Max. Efficiency (Battery Mode)	90%@12VDC
Charger (PV/AC)
Solar Charger Type	MPPT
Max PV input current / power	14A/1000W
Operating Voltage Range (VDC)	18~100
Max PV Open Circuit Voltage (VDC)	125
Max PV Charge Current (A)	60
Max AC Charge Current (A)	60
Max. Charge Current (PV + AC) (A)	120
Battery
Normal Voltage (VDC)	12.8
Floating Charge Voltage (VDC)	14
Overcharge Protection (VDC)	14.6
Battery Type	Lithium and Lead-acid
Interface
Reveal	LCD
Communication	RS485/RS232
General Data
Ingress Protection	IP21
Operating Temperature	-10 ℃~ 50 ℃
Relative Humidity	5% ~95% (Non-condensing)
Storage Temperature	-15*℃~60°℃
Max.Operating Altitude	4000m (Derating above 1000m)
Activation
AC Activation	YES
Pv Activation	YES
DIMENSION
LxWxH (products size, mm)	226330110mm
LxWxH (package size, mm)	286390170mm

>>>Our Factory

We are a manufacturer of Solar Energy Photovoltaic Products with many years history.
Our Factory produce Solar Power Inverter,AGM/GEL Lead Acid Battery Charger and Solar Charge Controller,etc.
Choosing Sunchonglic brand products are good choices.
More products information,please don't hesitate to contact us!

>>>Production Process

1.2kW Pure Sine Wave Solar Inverter with MPPT Dual AC / PV Charging & UPS Function 1

>>>FAQ

Q1. Are you the factory manufacturer?
A1. We are doing the Solar Energy Photovoltaic Products for over 20 years.
We are the original manufacturer and developer of advanced Solar Energy Photovoltaic
Product,including hybrid solar inverter, power inverter,battery chargers,solar controller,
and solar system,etc.
Q2.How to select a suitable products?
A2.Tell us your demand, we will recommend a suitable one to you.
Q3. What is your payment methods?
A3. We accept T/T,Trade Assurance,etc.
Q4. What’s the price terms can you offer for us?
A4. We can accept EXW, FOB, CIF and so on.
Q5. Where is your main market for your products?
A5. Most of our Sunchonglic brand products are exported to Southeast Asia, Africa and
Mid East etc.

Our products are widely recognized and trusted by our clients and can meet continuously
changing economic and social needs.
We would sincerely welcome new and old customers from over the world to visit and
contact us for future business relationships and mutual success!
