1000W Pure Sine Wave Inverter with 30A MPPT Solar Charger and High Conversion Efficiency for Reliable Power Supply

1000W Pure Sine Wave Inverter with 30A MPPT Solar Charger and High Conversion Efficiency for Reliable Power Supply

Brand Name:	Sunchonglic
Model Number:	SMS-1000A+MPPT
MOQ:	20pcs
Price:	US $31.05-155.25
Payment Terms:	T/T
Supply Ability:	100000pcs/mon

Detail Information

Product Description

Detail Information

Place of Origin:

China

Product Name:

1000W 12v Pure Sine Wave Inverter With 30A MPPT Channel Solar Charger

Battery Overvoltage Recovery:

14-14.5V

Working Environment Temperature:

-40~70℃

Overload Protection:

Turn Off Output And Resume After Restart

Battery Low Voltage Recovery:

11.5-12V

AC Voltage:

220VAC

Conversion Efficiency:

>90%

High Pressure Cut Off:

15V+/-0.5V

Low Voltage Alarm:

11.2V+/-0.3V

Low Cut:

10V+/-0.3V

Cooling Mode:

Fan Cooled

Packaging Details:

Paper Box

Highlight:

1000W Pure Sine Wave Inverter

30A MPPT Solar Charger Inverter

High Conversion Efficiency Power Inverter

Product Description

1000W 12V Pure Sine Wave Inverter With 30A MPPT Channel Solar Charger

This advanced 1000W 12V pure sine wave inverter integrates a 30A MPPT solar charger, providing reliable power conversion and efficient solar energy harvesting in a single compact unit.

Product Features

External Battery Design: Utilizes external batteries for enhanced inverter efficiency and reduced overload risk
Wide Voltage Input: Supports DC 10-32V (12V) or DC 20-64V (24V) input, compatible with various battery types
Multi-Output Ports: Features AC (220V/50Hz pure sine wave) and DC outputs to power diverse devices
Smart Power Switching: Automatically switches between utility power (with charging) and battery power during outages
Comprehensive Protections: Includes over-voltage, under-voltage, overload, short-circuit, over-heat, and reverse-polarity protection
High Surge Power: Peak power up to 2x rated power (2000W for 1000W model) to handle high-startup-current devices

Technical Specifications

Model	SMS-1000A+MPPT	SMS-1000B+MPPT	SMS-1500A+MPPT	SMS-1500B+MPPT
The built-in controller	25A-30A	20A-25A	50A-60A	50A-60A
Featured solar panel specifications	100~200W/36Vx2	200~300W/36Vx2	100~150W/36Vx4	100~150W/36Vx4
External battery	12V 100Ah~150Ah	24V 100Ah~150Ah	12V 100Ah~150Ah	24V 100Ah~150Ah
Output voltage of the inverter	AC 220V+/-5%	AC 220V+/-5%	AC 220V +/-5%	AC 220V +/-5%
Maximum continuous power	1000W	1000W	1500W	1500W
Peak power	2000W	2000W	3000W	3000W
No load current	<0.5A	<0.3A	<0.5A	<0.3A
DC input voltage	DC9.7V~15.5V	DC20V~32V	DC9.7V~15.5V	DC20V~32V
Output frequency	50+/-3Hz	50+/-3Hz	50+/-3Hz	50+/-3Hz
Conversion efficiency	>90%	>90%	>90%	>90%
High pressure cut off	15V+/-0.5V	31V+/-0.5V	15V+/-0.5V	31V+/-0.5V
Low voltage alarm	11.2V+/-0.3V	22V+/-0.3V	11.2V+/-0.3V	22V+/-0.3V
Low cut	10V+/-0.3V	20V+/-0.3V	10V+/-0.3V	20V+/-0.3V
Overload, short circuit protection	There are	There are	There are	There are
Output waveform	Fixed wave	Fixed wave	Fixed wave	Fixed wave
Cooling mode	Fan cooled	Fan cooled	Fan cooled	Fan cooled
Working environment temperature	-20℃~+70℃	-20℃~+70℃	-20℃~+70℃	-20℃~+70℃
Relative humidity	<90%RH	<90%RH	<90%RH	<90%RH

Manufacturing Excellence

With decades of experience in the solar energy photovoltaic industry, our factory specializes in manufacturing premium solar power inverters, AGM/GEL lead-acid battery chargers, solar charge controllers, and innovative energy solutions.

Production Process

Frequently Asked Questions

Are you the factory manufacturer?

With over two decades of expertise in solar energy photovoltaic solutions, we are the original manufacturer and technology pioneer specializing in integrated solar products including hybrid solar inverters, power inverters, battery chargers, solar controllers, and comprehensive solar systems.

How to select a suitable product?

Tell us your requirements and we will recommend the most suitable product for your needs.

What are your payment methods?

We accept T/T, Trade Assurance, and other secure payment options.

What price terms can you offer?

We can accommodate EXW, FOB, CIF, and other international trade terms.

Where is your main market?

Our Sunchonglic brand products are exported worldwide with strong presence in Southeast Asia, Africa, Middle East, and other regions.

Our products are widely recognized and trusted by clients worldwide, designed to meet continuously evolving economic and social needs. We welcome both new and existing customers to contact us for future business relationships and mutual success.
