Double MOS Three Phase Charging LCD Display PWM Solar Charge Controller for 12V 24V Solar Regulator Systems

Name: Double MOS Three Phase Charging LCD Display PWM Solar Charge Controller for 12V 24V Solar Regulator Systems
Brand: Foshan Suntway Technology Co. Ltd.
SKU: FT-S1230
Price: 14.98 USD
Availability: InStock

Brand Name:	Sunchonglic
Model Number:	FT-S1230
MOQ:	100pcs
Price:	US $3.98-27.89
Payment Terms:	T/T
Supply Ability:	100000pcs/mon

Detail Information

Product Description

Detail Information

Place of Origin:

China

Product Name:

FT-S1230 Double MOS LCD Display 30A PWM Solar Charge Controller For 12V 24V Systems With Three Phase Charging

Rated current:

30A

Charging Voltage:

14.6V(B03)

Low Power Recovery Voltage:

12V(B03)

Working Temperatue:

-35℃~+60℃

Size / Weight :

125*85*30mm/220g

Packaging Details:

Paper Box

Highlight:

Double MOS PWM Solar Charge Controller

Three Phase Charging Solar Charge Controller

LCD Display Solar Regulator

Product Description

Double MOS LCD Display PWM Solar Charge Controller

Advanced 12V/24V 30A three-phase PWM solar charge controller with LCD display for efficient solar power management.

Product Features

Compatible with three battery types: Lead Acid, Lithium Ion, and Lithium Iron Phosphate
Large LCD screen with fully customizable charging and discharging parameters; power-off memory retains the last setting
Three-phase PWM charge management: constant current, constant voltage, and floating charge mode
Built-in multiple protections: overcurrent, short circuit, open circuit, and battery reverse connection protection
Double MOS tube anti-reverse circuit prevents battery backflow to the solar panel at night, reducing power loss
Dual USB 5V/2A output for charging phones and small devices
Low standby consumption with a wide working temperature range of -35℃ to +60℃

Product Specifications

Model	FT-S1230
System Voltage	12V/24V
Maximum Input Voltage	<50V
Rated Current	30A
External 12V Battery Recommended Solar Panel Specifications	100-150W/18V
External 24V Battery Recommended Solar Panel Specifications	100-150W/36V
External Battery	12V 100-150Ah 24V 100-150Ah
Battery Type	B01 = Lead Acid Battery 12V B02 = Lithium-ion battery 3 series 3.7V = 11.1V B03 = Lithium iron phosphate battery 4 series 3.2V = 12.8V
Charging Voltage	14.6V (B03)
Low-Voltage Cut-Off Voltage	10V (B03)
Low Power Recovery Voltage	12V (B03)
USB Output	5V/2A
Standby Current	<10mA
Working Temperature	-35℃ ~ +60℃
Size / Weight	125 * 85 * 30 mm / 220 g

Our Factory

With over a decade of expertise, we specialize in advanced solar solutions, manufacturing high-performance inverters, AGM/GEL battery chargers, and smart controllers for residential and commercial use. Engineered with cutting-edge technology and rigorously tested, our products ensure reliability and efficiency.

Contact our team for tailored solutions to maximize your solar investment.

Production Process

Frequently Asked Questions

Q1. Are you the factory manufacturer?

A1. We have been producing solar energy photovoltaic products for over 20 years. We are the original manufacturer and developer of advanced solar energy photovoltaic products, including hybrid solar inverters, power inverters, battery chargers, solar controllers, and solar systems.

Q2. How do I select a suitable product?

A2. Tell us your requirements, and we will recommend a suitable product for you.

Q3. What are your payment methods?

A3. We accept T/T, Trade Assurance, and other methods.

Q4. What price terms can you offer?

A4. We can accept EXW, FOB, CIF, and other terms.

Q5. Where is your main market?

A5. Most of our Sunchonglic brand products are exported to Southeast Asia, Africa, the Middle East, and other regions.

Application

Widely used for home solar lighting systems, off-grid solar power stations, solar home kits, and outdoor solar power supply.

Our products are widely recognized and trusted by our clients and can meet continuously changing economic and social needs.

We sincerely welcome new and old customers from around the world to visit and contact us for future business relationships and mutual success.
