Brand Name: | Sunchonglic |
Model Number: | FPV-7.5KVA |
MOQ: | 5pcs |
Price: | US $274.62-1273.85 |
Payment Terms: | ,T/T |
Supply Ability: | 100000pcs/mon |
What is feature of hybrid solar inverter without battery 7500w 7.5kw off grid MPPT 450V PV ?
1. PV array voltage input range is from 260V DC to 450V DC, allowing for a wide range of solar panel configurations .
2. No extra external battery is needed, making this solar system more economical and affordable for home use .
3. The system provides a grid output of 220V AC, suitable for direct connection to the electrical grid .
4. It also includes a built-in 12V DC output interface (optional), which can be used for additional devices or systems .
5. Various safe protections are included, such as anti-islanding defense, to ensure the system operates safely under different conditions .
6. The system is equipped with a built-in uninterrupted power supply, ensuring continuous power during grid outages or other disruptions .
>>>Product Specifications
Model | FPV-7.5KVA | |
PV DC input paramerters | Maximum input power(W) | 5000W |
PV input voltage range(Vdc) | 260VDC-450CVDC | |
PV max input current(Idc) | 18 | |
AC input parameters | AC input range(Vac) | 150VAC-300VAC |
AC rated voltage(Vac) | 220VAC | |
AC output parameters | Peak output power (W) | 6000 |
Rated output power(W) | 5000 | |
Output waveform | Pure sine wave | |
Output voltage range(Vac) | 160VAC-240VAC | |
Maximum output current(A) | 25A | |
Rated output voltage(Vac) | 220V/230 | |
Rated output current(A) | 22.7A | |
Output frequency range(Hz) | 40Hz-50Hz | |
Current harmonics(at rated power) | <5% | |
Maximum efficiency | 95% | |
Environmental parameters | Operating temperature range(℃) | -25~+60 |
Relative humidity | 0-95% No condensation | |
Altitude(m) | ≤2000 | |
Cooling method | Fan cooling | |
Nighttime energy consumption(W) | <0.2 | |
Noise decibel(dB) | <50 | |
Communication | LCD | 2 lines of charcter of display |
Mechanical properties | Dimensions(Width x depth x heigh)mm | 375*330*125 |
Weight(KG) | 5.6 |
Q1. Are you the factory manufacturer?
A1. We are doing the Solar Energy Photovoltaic Products for over 20 years.
We are the original manufacturer and developer of advanced Solar Energy Photovoltaic
Product,including hybrid solar inverter, power inverter,battery chargers,solar controller,
and solar system,etc.
Q2.How to select a suitable products?
A2.Tell us your demand, we will recommend a suitable one to you.
Q3. What is your payment methods?
A3. We accept T/T and Trade Assurance,etc.
Q4. What’s the price terms can you offer for us?
A4. We can accept EXW, FOB, CIF and so on.
Q5. Where is your main market for your products?
A5. Most of our Sunchonglic brand products are exported to Southeast Asia, Africa and
Mid East etc.
Our products are widely recognized and trusted by our clients and can meet continuously
changing economic and social needs.
We would sincerely welcome new and old customers from over the world to visit and
contact us for future business relationships and mutual success!
