24V 3000W Hybrid Solar Inverter with Pure Sine Wave Output and Intelligent Temperature Control

Brand Name:	Sunchonglic
Model Number:	HMP-3KVA-24V
MOQ:	5pcs
Price:	US $274.62-1273.85
Payment Terms:	T/T
Supply Ability:	100000pcs/mon

Detail Information

Product Description

Detail Information

Place of Origin:

China

Product Name:

24v 3kw 3000w 3000 Watt Off Grid Mppt Inverter Hybrid Low Frequency Hybrid Solar Inverter

Transfer Time:

<5ms

Output Frequency:

50Hz/60Hz Can Adjust At Site

Heat-dissipating Type:

Intelligent Temperature Control

Peak Capacity:

15kw

DC Input Voltage Range:

10.5VDC-15VDC (single Battery Voltage 12V)

Packaging Details:

Paper Box

Highlight:

24v Solar Hybrid Inverter 3000w

Residential Applications Solar Hybrid Inverter 3000w

High Accuracy Solar Panel Power Inverter

Product Description

24V Solar Hybrid Inverter 3000W - Power Saving High Accuracy for Residential Applications

This 24V 3kW 3000W off-grid MPPT hybrid low frequency solar inverter delivers reliable power conversion with advanced energy management capabilities for residential applications.

Key Features

Pure sine wave output with built-in transformer and AVR stabilizer - specially designed for inductive loads like air conditioners, refrigerators, motors, water pumps, compressors, and laser printers
Three working modes: Battery priority, PV priority, Mains priority
Optional RS232/RS485 communications port
Built-in 60A/80A/160A MPPT solar controller and AC charger
High conversion efficiency up to 90%
Built-in Lithium battery activation function

Technical Specifications

Model Capacity	3kW
Peak Capacity	9kW
Battery Voltage	12V/24V/48V
Inbuilt MPPT Charging Current	60A
PV Input Port	One route (60A)
PV Input Voltage Range	15V-180V (12V system); 30V-180V (24V system); 60V-180V (48V system)
Max PV Input Capacity	60A: 720W (12V system) 1440W (24V system) 2880W (48V system)
Max Charging Current (adjustable)	OFF 30A/60A (can switch OFF PV charging)
MPPT Efficiency	≈99%
Unattended Mode	Inverter is OFF mode: MPPT can charge battery if there is sunshine
DC Input Voltage Range	10.5VDC-15VDC (single battery voltage 12V)
AC Input Voltage Range	110VAC: (80-130)VAC; 220VAC: (160-260)VAC/(130-280)VAC (adjustable on-site)
AC Input Frequency	45HZ-65HZ auto test
AC Charging Current	OFF (can switch off AC charging function)
Output Wave	Pure sine wave
Output Efficiency	≈90%
Output Voltage	200V/210V/220V/230V/240V (adjustable on-site)
Output Frequency	50Hz/60Hz (adjustable on-site)
ECO Mode and Loss	5W
Inverter Working Modes	AC priority, DC priority, ECO mode, unattended mode, generator mode
LCD Display Working Mode	Normal mode/"ON" mode
Battery Types	Lead-acid battery/GEL battery/lithium iron phosphate battery/ternary lithium battery/customized battery
Battery Customized Parameters	Constant voltage charging, Floating charging, battery recover, AC recover, low voltage alarm and low voltage protection
Battery Charging Types	Lead-acid: three steps, constant current charging, constant voltage charging, floating charging Lithium battery: constant current charging, constant voltage charging
Lithium Battery String Numbers	Lithium iron phosphate battery: 3.2V single one Ternary lithium battery: 3.7V single one
Protections	Battery low voltage/battery over voltage/over load protection/high temperature protection/charging type protections
LCD Display	AC station, DC station, charging station and alarm
Front Panel Display	Working station, input and output voltage, PV parameters and inverter parameters
Language	Chinese/English can choose
Transfer Time	<5ms
Heat-dissipating Type	Intelligent temperature control
Communications	RS232/RS485 (optional)
Working Temperature	(-10℃~40℃)
Altitude	≤3000m
Inverter Size (LWHmm)	495320220mm
Packing Size (LWHmm)	600380290mm
Net Weight (kg)	19.5kg
Gross Weight (kg)	22kg

Manufacturing Excellence

With over a decade of expertise in solar energy solutions, we are a leading manufacturer specializing in photovoltaic products. Our facility produces high-performance solar power inverters, AGM/GEL lead-acid battery chargers, and solar charge controllers, offering comprehensive solutions for residential and commercial applications. Sunchonglic products deliver cutting-edge technology with a proven track record of reliability.

Professional Support

For detailed product specifications, please contact our professional team for prompt assistance!

Frequently Asked Questions

Are you the factory manufacturer?

With over two decades of expertise in solar energy photovoltaic solutions, we are the original manufacturer and technology pioneer specializing in integrated solar products. Our core innovations include hybrid solar inverters that combine inverter and controller functionalities, power inverters, battery chargers, solar controllers, and comprehensive solar systems.

How to select a suitable product?

Tell us your demand, we will recommend a suitable one to you.

What are your payment methods?

We accept T/T, Trade Assurance, etc.

What price terms can you offer?

We can accept EXW, FOB, CIF and so on.

Where is your main market?

Most of our Sunchonglic brand products are exported to Southeast Asia, Africa and Mid East etc.

Our products are widely recognized and trusted by clients globally and consistently meet the continuously evolving economic and social demands. We sincerely welcome both existing and potential customers worldwide to visit us and establish contact, fostering long-term business partnerships for mutual success!
