575Wp Solar Panel with 1500V DC and Advanced Non-Destructive Cutting for Enhanced Efficiency

Brand Name:	Sunchonglic
Model Number:	SUN 575Wp
MOQ:	20pcs
Price:	Negotiate
Payment Terms:	,T/T
Supply Ability:	100000pcs/mon

Detail Information

Product Description

Detail Information

Place of Origin:

China

Product Name:

575Wp Solar Panel 182m / 144tb 1500v Dc

OperatingTemperature :

40℃~85℃

Open Circuit Voltage-VocV):

52.93

Fuse Rating(A):

Short Circuit Current-Isc(A):

13.69

Max. Power Voltage-Vmpp(V):

4.61

Packaging Details:

Paper Box

Highlight:

575 Wp Solar Panel

575 Wp 144tb Solar Panel

144tb Solar Panel

Product Description

575Wp Solar Panel - 182mm / 144 Cell - 1500V DC

High-performance 575Wp solar panel featuring advanced N-TOPCon mono cell technology with 1500V DC system voltage capability.

Product Features

Advanced Non-Destructive Cutting (NDC) maintains cell integrity and minimizes power loss
Laser-welded junction box ensures secure connections for improved safety and reliability
Excellent low-light performance delivers superior power generation under cloudy conditions
Comprehensive warranty coverage: 15-year product warranty and 30-year linear power output warranty
Light redirecting film technology enhances rear-side light absorption while ensuring bifacial reliability

Electrical Characteristics (STC*)

Parameter	560W	565W	570W	575W	580W	585W	590W	595W	600W
Rated Power Pmax (Wp)	560	565	570	575	580	585	590	595	600
Open Circuit Voltage Voc (V)	52.45	52.61	52.77	52.93	53.09	53.25	53.41	53.57	53.73
Short Circuit Current Isc (A)	13.47	13.55	13.62	13.69	13.76	13.83	13.89	13.95	14.01
Max Power Voltage Vmpp (V)	44.12	44.26	44.39	44.61	44.84	45.06	45.28	45.50	45.72
Max Power Current Impp (A)	12.71	12.79	12.85	12.90	12.95	13.00	13.06	13.12	13.18
Module Efficiency (%)	21.67	21.86	22.06	22.25	22.44	22.63	22.82	23.02	23.22

Additional STC Parameters:
Maximum system voltage: 1500V DC
Fuse Rating: 30A
Temperature coefficient Pmax: -0.29%/℃
Temperature coefficient Isc: 0.045%/℃
Temperature coefficient Voc: -0.25%/℃
Referential Bifacial Factor: 80±5%
*STC: Irradiance 1000W/m², module temperature 25℃, AM=1.5

Working Characteristics (NOCT*)

Parameter	421W	425W	429W	432W	436W	440W
Rated Power Pmax (Wp)	421	425	429	432	436	440
Open Circuit Voltage Voc (V)	48.13	48.32	48.51	48.70	48.89	49.08
Short Circuit Current Isc (A)	11.41	11.46	11.50	11.55	11.60	11.65
Max Power Voltage Vmpp (V)	39.39	39.52	39.65	39.78	39.87	40.00
Max Power Current Impp (A)	10.69	10.75	10.81	10.87	10.94	11.01

Additional NOCT Parameters:
Power tolerance: 0~+3%
NOCT: 45℃±2℃
Operating Temperature: 40℃~85℃
*NOCT: Irradiance 800W/m², ambient temperature 20℃, wind speed 1m/s

Bifacial Performance Characteristics

Rear Side Gain	Pmax (W)	Voc (V)	Isc (A)	Vmpp (V)	Impp (A)
5%	630	53.73	14.71	45.72	13.84

The additional gain from the rear side compared to the power of the front side at standard test condition. Performance depends on mounting configuration (structure, height, tilt angle) and ground albedo.

Mechanical Characteristics

Number of cells: 144 pcs
Type of cell: N-TOPCon Mono
Type of frame: Anodized Aluminum Alloy
Module dimensions: 2279 * 1134 * 35 mm
Glass thickness: 2.0 mm
Weight: 32 kg
Junction box: IP68, 1500V DC, 3 Diodes
Cables/connectors: 4.0mm², MC4 compatible
Cable length: +300mm/-200mm (connector included)
Custom cable lengths available

Packaging Configuration

Parameter	Option 1	Option 2
Height of Modules (mm)	35	30
Number of Modules Per Pallet	31	36
Packaging Box Dimensions (lwh) (mm)	230011201260	230011201260
Box Gross Weight (kg)	1020	1180
Number of Modules Per 40ft (HQ) Container	620	720
Number of Pallets Per 40ft (HQ) Container	20	20

Manufacturer Profile

As a seasoned manufacturer with over 20 years of experience, we specialize in producing comprehensive solar photovoltaic products including solar power inverters, AGM/GEL lead-acid battery chargers, solar charge controllers, and other key components. Our Sunchonglic products offer high performance, reliability, and cost-effectiveness for diverse applications.

Our product line includes pure sine wave inverters, modified sine wave inverters, UPS chargers, voltage stabilizers, Gel/AGM/SLA battery chargers, lithium-ion battery chargers, PWM and MPPT solar charge controllers, and portable power stations.

Backed by advanced testing equipment and a strong R&D team, we continuously optimize product performance to meet the needs of various industries and application scenarios. We also provide customized solutions to ensure flexibility in meeting special customer requirements.

With a 10,000-square-meter logistics center and complete after-sales service system, our Sunchonglic solar products have been widely adopted in markets across the Middle East, Southeast Asia, Africa, and South America, earning the trust of customers worldwide.

Frequently Asked Questions

Q1. Are you the factory manufacturer?

We have been manufacturing Solar Energy Photovoltaic Products for over 20 years. We are the original manufacturer and developer of advanced solar energy photovoltaic products, including hybrid solar inverters, power inverters, battery chargers, solar controllers, and complete solar systems.

Q2. How to select a suitable product?

Tell us your specific requirements and we will recommend the most suitable product for your application.

Q3. What are your payment methods?

We accept T/T, Trade Assurance, and other secure payment methods.

Q4. What price terms can you offer?

We can accommodate various price terms including EXW, FOB, CIF, and others.

Q5. Where is your main market?

Our Sunchonglic brand products are primarily exported to Southeast Asia, Africa, the Middle East, and other global markets.

Our products have earned global acclaim and client trust, adeptly addressing evolving economic and societal demands. We warmly welcome customers worldwide to collaborate in building lasting partnerships for mutual growth and success!
