585Wp Solar Panel 144tb 1500V DC Photovoltaic Module for High Efficiency Solar Energy

Brand Name:	Sunchonglic
Model Number:	SUN 585Wp
MOQ:	20pcs
Price:	Negotiate
Payment Terms:	,T/T
Supply Ability:	100000pcs/mon

Detail Information

Product Description

Detail Information

Place of Origin:

China

Product Name:

585Wp Solar Panel 182m / 144tb 1500v Dc

Refer. Bifacial Factor:

80±5%

Temperature Coefficient Lsc:

0.045%/℃

NOCT:

45℃±2℃

Max. Power Voltage-Vmpp(V):

45.06

Power Tolerance:

0~+3%

Packaging Details:

Paper Box

Highlight:

182m 585Wp Solar Panel

1500v Dc 585Wp Solar Panel

144tb 585Wp Solar Panel

Product Description

585Wp Solar Panel 182m / 144tb 1500v DC

High-efficiency solar panel designed for maximum energy output and long-term reliability in industrial applications.

Product Features

Light Redirecting Film: Utilizes gap light redirecting film technology to enhance bifaciality and module reliability while improving power performance.
No-Destructive Cutting: Employs non-destructive cutting technology that ensures smooth cutting surfaces and preserves cell integrity and current flow.
Junction Box Laser Welding: Features high-energy laser welding with precise positioning control for improved module safety and reliability.
Higher Power Output: Module power increases by 5-25%, resulting in lower levelized cost of electricity and higher internal rate of return with 0-5W positive tolerance output warranty.
PID Resistance: Optimized mass production and material control ensure excellent anti-PID performance for enhanced long-term reliability.
Environmental Durability: Certified for high salt mist and ammonia resistance by TUV NORD, demonstrating robustness against extreme environmental conditions.

Product Specifications

Electrical Characteristics (STC*)

Parameter	560	565	570	575	580	585	590	595	600
Rated Power - Pmax (Wp)	560	565	570	575	580	585	590	595	600
Open Circuit Voltage - Voc (V)	52.45	52.61	52.77	52.93	53.09	53.25	53.41	53.57	53.73
Short Circuit Current - Isc (A)	13.47	13.55	13.62	13.69	13.76	13.83	13.89	13.95	14.01
Max. Power Voltage - Vmpp (V)	44.12	44.26	44.39	44.61	44.84	45.06	45.28	45.50	45.72
Max. Power Current - Impp (A)	12.71	12.79	12.85	12.90	12.95	13.00	13.06	13.12	13.18
Module Efficiency (%)	21.67	21.86	22.06	22.25	22.44	22.60	22.80	23.02	23.22

Additional Electrical Parameters:
Maximum system voltage: 1500V DC
Fuse Rating: 30A
Temperature coefficient Pmax: -0.29%/℃
Temperature coefficient Isc: 0.045%/℃
Temperature coefficient Voc: -0.25%/℃
Refer. Bifacial Factor: 80±5%
*STC: Irradiance 1000W/m², module temperature 25℃, AM=1.5

Working Characteristics (NOCT*)

Parameter	421	425	429	432	436	440
Rated Power - Pmax (Wp)	421	425	429	432	436	440
Open Circuit Voltage - Voc (V)	48.13	48.32	48.51	48.70	48.89	49.08
Short Circuit Current - Isc (A)	11.41	11.46	11.50	11.55	11.60	11.65
Max. Power Voltage - Vmpp (V)	39.39	39.52	39.65	39.78	39.87	40.00
Max. Power Current - Impp (A)	10.69	10.75	10.81	10.87	10.94	11.01

Power tolerance: 0~+3%
NOCT: 45℃±2℃
Operating Temperature: -40℃~85℃
*NOCT: Irradiance 800W/m², ambient temperature 20℃, wind speed 1m/s

Mechanical Characteristics

Number of cells: 144pcs
Type of frame: Anodized Aluminum Alloy
Type of cell: N-TOPCon Mono
Size of module: 2279*1134*35 mm
Thickness of glass: 2.0 mm
Weight: 32 kg
Junction box: IP68, 1500V DC, 3 Diodes
Cables/connectors: 4.0mm², MC4 compatible
Length of Cable: +300mm/-200mm (connector included)
Length can be customized

Packaging Configuration

Parameter	Option 1	Option 2
Height of Modules (mm)	35	30
Number of Modules Per Pallet	31	36
Packaging Box Dimensions (lwh) (mm)	230011201260	230011201260
Box Gross Weight (kg)	1020	1180
Number of Modules Per 40ft (HQ) Container	620	720
Number of Pallets Per 40ft (HQ) Container	20	20
