4.2kw Output 48V Battery Voltage Hybrid Solar Inverter with 70V-450V PV Input

Brand Name:	Sunchonglic
Model Number:	SUN 4.2KW48
MOQ:	100pcs
Price:	US $274.62-1273.85
Payment Terms:	,T/T
Supply Ability:	100000pcs/mon

Detail Information

Product Description

Detail Information

Place of Origin:

China

Product Name:

4.2kw 48V Output Hybrid Solar Inverter With 70V-450V PV Input And 2KW 230Vac Output

Nominal Battery Voltage:

48V

Battery Voltage Range:

41-58V

MPPT Operating Voltage Range:

70-400VDC

Max. Input Current MPPT:

18A

Start-up Voltage:

80VDC

Packaging Details:

Paper Box

Highlight:

48V hybrid solar inverter

4.2kw hybrid solar inverter

70v-450v PV input inverter

Product Description

4.2kW 48V Output Hybrid Solar Inverter with 70V-450V PV Input

Product Features

Operates with solar or grid power without batteries, featuring integrated dustproof durability
Wide PV input range (70V-450V DC) enables flexible solar panel configurations
Real-time tracking of total and daily PV generation accessible via display or remote interfaces
RS-485 communication with BMS provides precise battery status and health monitoring
Surplus solar energy feeds back to the grid where permitted by local regulations

Product Specifications

MODEL	SUN 2.2K24	SUN 3.2K24	SUN 4.2K24	SUN 4.2K48
PV Array
Max. PV Array Power	2400W	3600W	4600W	4600W
Max. PV Array Open-Circuit Voltage	450VDC
Start-up Voltage	80VDC
MPPT Operating Voltage Range	70-400VDC
Nominal Input Voltage	300VDC
Max. Input Current MPPT	18A
MPPT max Efficiency	99%
Battery
Battery Type	Li-ion / lead-acid
Nominal Battery Voltage	24V	24V	24V	48V
Battery Voltage Range	21-29V	21-29V	21-29V	41-58V
Max. AC Charging Current	40A	40A	40A	40A
Max. PV Charging Current	80A	80A	100A	60A
Max. Continuous Discharging Current	80A	100A	120A	80A
AC Input
Nominal Voltage	230VAC
Voltage Range	170-275VAC
Frequency	50/60Hz (Auto following)
Max. Input Current	20A	25A	25A	25A
AC Output
Nominal Voltage	220/230VAC ±5%
Output Voltage Waveform	Pure Sine Wave
Rated Output Power	2200VA/2200W	3200VA/3200W	4200VA/4200W	4200VA/4200W
Peak Output Power	3200VA	4400VA	6100VA	6100VA
Nominal Output Frequency	50/60Hz
Transfer Time	10ms
Efficiency (peak) PV to INV	96.5%
Efficiency (peak) BAT to INV	93.0%
General Data
Operating Temperature Range	-10°C to +50°C
Relative Humidity	0-95%
Max. Operating Altitude	< 4000m
Cooling Method	Intelligent Fan cooling
Display	LED + LCD
Communication with BMS	RS485
Communication with Cloud	WiFi/4G
Degree of Protection	IP21
Weight (kg)	5.9	6.1	6.1	6.1
Dimension (WHD mm)	34395275
Mounting Method	Wall Mounted

Our Factory

With over 10 years as a solar photovoltaic manufacturer, we deliver premium power solutions including solar inverters, AGM/GEL battery chargers, and solar charge controllers. Sunchonglic products guarantee reliability and quality.

For complete product specifications, please contact us today!

Production Process

Frequently Asked Questions

Q1. Are you the factory manufacturer?

A1. We have been manufacturing Solar Energy Photovoltaic Products for over 20 years. We are the original manufacturer and developer of advanced Solar Energy Photovoltaic Products, including hybrid solar inverters, power inverters, battery chargers, solar controllers, and solar systems.

Q2. How to select a suitable product?

A2. Tell us your requirements, and we will recommend a suitable product for you.

Q3. What are your payment methods?

A3. We accept T/T, Trade Assurance, and other payment methods.

Q4. What price terms can you offer?

A4. We can accept EXW, FOB, CIF, and other terms.

Q5. Where is your main market?

A5. Most of our Sunchonglic brand products are exported to Southeast Asia, Africa, and the Middle East.

Our products are widely recognized and trusted by our clients and can meet continuously changing economic and social needs.

We sincerely welcome new and existing customers from around the world to visit and contact us for future business relationships and mutual success!
