5000w Solar Pure Sine Wave Low Frequency Mppt Hybrid Solar Inverter

Brand Name:	Sunchonglic
Model Number:	HMP-5KVA-48V
MOQ:	5pcs
Price:	US $274.62-1273.85
Payment Terms:	T/T
Supply Ability:	100000pcs/mon

Detail Information

Product Description

Detail Information

Place of Origin:

China

Product Name:

5000w Solar Pure Sine Wave Low Frequency Mppt Hybrid Solar Inverter

Peak Capacity:

15kw

DC Input Voltage Range:

10.5VDC-15VDC (single Battery Voltage 12V)

Output Efficiency:

≈90%

Heat-dissipating Type:

Intelligent Temperature Control

PV Input Port:

One Route(60A)

Packaging Details:

Paper Box

Product Description

5000w Solar Pure Sine Wave Low Frequency Mppt Hybrid Solar Inverter

>>>Product Description

What is feature of 5000w solar pure sine wave low frequency mppt hybrid solar inverter?

1.Compatible with lead-acid, gel, lithium iron phosphate, custom, and ternary lithium batteries
2.Offers three operational modes: Battery Priority, PV Priority, and Mains Priority
3.RS232/RS485 communication ports are available as an optional feature
4.The PV array supports an open-circuit input voltage of 230V DC
5.Achieves a high conversion efficiency of up to 90%
6.Includes an inbuilt lithium battery activation function

5000w Solar Pure Sine Wave Low Frequency Mppt Hybrid Solar Inverter 0

>>>Product Specifications

Model	Capacity	5kw
	Peak capacity	15kw
	Battery voltage	24v/48v
Inbuilt MPPT	Charging current	60A
	PV input port	One route(60A)
	PV input voltage range	15V-180V(12V system); 30V-180V(24V system); 60V-180V(48V system)
	Max PV input capacity	60A: 720W (12V system) 1440W(24V system) 2880W(48V system)
	Max charging current,can be adjustable	OFF 30A/60A(can switch OFF PV charging)
	MPPT efficiency	≈99%
	Unattended mode	Inverter is OFF mode:MPPT can charge battery if there is sunshine
Input	DC input voltage range	10.5VDC-15VDC (single battery voltage 12V)
	AC input voltage range	110VAC:(80-130)VAC; 220VAC: (160-260)VAC/(130-280)VAC,can ajdust at site
	AC input frequency	45HZ-65HZ auto test
	AC charging current can choose	OFF(can switch off AC charging function)
Output	Output wave	Pure sine wave
	Output efficiency	≈90%
	Output voltage	200V/210V/220V/230V/240V can adjust at site
	Output frequency	50Hz/60Hz can adjust at site
	ECO mode and loss	5W
Working mode	Inverter working mode	AC priority, DC priority, ECO mode, unattended mode, generator mode
Working mode	LCD display working mode	Normal mode/"ON" mode
Battery parameter	Battery types	Lead-acid battery/GEL battery/ lithium iron phosphate battery/ ternary lithium battery/customized battery
	Battery customized parameters	Constant voltage charging, Floating charging, battery recover, AC recover, low voltage alarm and low voltage protection
	Battery charging types	Lead-acid: three steps, constant current charging, constant voltage charging, floating charging Lithium battery: constant current charging, constant voltage charging
	Lithium battery string numbers can choose	lithium iron phosphate battery:3.2V single one ternary lithium battery:3.7V single one
Protections		Battery low voltage/battery over voltage/over load protection/ high temperature protection/ charging type protections
LCD display	LCD display	AC station, DC station, charging station and alarm
	Front panel display	Working station, input and output voltage, PV parameters and inverter parameters
	Language	Chinese/English can choose
Transfer time		<5ms
Heat-dissipating type		Intelligent temperature control
Communications		RS232/RS485(can choose)
Working temperature		(-10℃~40℃)
Altitude		≤3000m
Inverter size (LWHmm)		495320220mm
Packing size (LWHmm)		600380290mm
Net weight(kg) (About)		25kg
Gross weight (kg) (About)		28kg
