Hybrid Solar Inverter 3.2kW Output Power with 70V-450V Photovoltaic Input and 230V AC

Hybrid Solar Inverter 3.2kW Output Power with 70V-450V Photovoltaic Input and 230V AC

Brand Name:	Sunchonglic
Model Number:	SUN 3.2KW24
MOQ:	100pcs
Price:	US $274.62-1273.85
Payment Terms:	,T/T
Supply Ability:	100000pcs/mon

Detail Information

Product Description

Detail Information

Place of Origin:

China

Product Name:

Hybrid Solar Inverter 3.2kW Output Power 230V AC Supporting 70V-450V Photovoltaic Inputt

Max. Continuous Discharging Current:

100A

Voltage Range:

170-275VAC

Frequency:

50/60Hz (Auto Following)

Display:

Display

Mounting Method:

Wall Mounted

Packaging Details:

Paper Box

Highlight:

3.2kw hybrid solar inverter

230v AC hybrid inverter

solar inverter with 70v-450v input

Product Description

Hybrid Solar Inverter 3.2kW Output Power

230V AC supporting 70V-450V photovoltaic input for reliable solar energy conversion

Key Features

Patented Passive Dust-Proof Architecture: Eliminates filter maintenance while ensuring reliable operation in harsh sandy environments, reducing OPEX by 20%
Battery-Free Operation Mode: Directly powers critical loads during emergencies without battery backup, achieving 50% faster response time in grid-outage scenarios
Industry's Widest MPPT Voltage Window (60-450VDC): Boosts weak-light harvest by 15% and doubles PV string configuration flexibility for complex installations
Dual-Layer PV Performance Intelligence: Real-time lifetime/daily yield tracking with time-based analytics enables AI-powered anomaly detection for optimized ROI
Universal BMS Interoperability: Seamless RS-485 integration with major battery brands enables dynamic charge/discharge optimization via open-protocol communication
Smart Surplus Energy Dispatch 2.0: Programmable grid feed-in with time-of-use tariff synchronization maximizes ROI through intelligent energy arbitrage

Technical Specifications

MODEL	SUN 2.2K24	SUN 3.2K24	SUN 4.2K24	SUN 4.2K48
PV Array
Max. PV Array Power	2400W	3600W	4600W	4600W
Max. PV Array Open-Circuit Voltage	450VDC
Start-up Voltage	80VDC
MPPT Operating Voltage Range	70-400VDC
Nominal Input Voltage	300VDC
Max. Input Current MPPT	18A
MPPT max Efficiency	99%
Battery
Battery Type	Li-ion / lead-acid
Nominal Battery Voltage	24V	24V	24V	48V
Battery Voltage Range	21-29V	21-29V	21-29V	41-58V
Max. AC Charging Current	40A	40A	40A	40A
Max. PV Charging Current	80A	80A	100A	60A
Max. Continuous Discharging Current	80A	100A	120A	80A
AC Input
Nominal Voltage	230VAC
Voltage Range	170-275VAC
Frequency	50/60Hz (Auto following)
Max. Input Current	20A 25A
AC Output
Nominal Voltage	220/230VAC±5%
Output Voltage Waveform	Pure Sine Wave
Rated Output Power	2200VA/2200W	3200VA/3200W	4200VA/4200W	4200VA/4200W
Peak Output Power	3200VA	4400VA	6100VA	6100VA
Nominal Output Frequency	50/60Hz
Transfer Time	10ms
Efficiency(peak) PV to INV	96.5%
Efficiency(peak) BAT to INV	93.0%
General Data
Operating Temperature Range	-10 - +50℃
Relative Humidity	0~95%
Max. Operating Altitude	< 4000m
Cooling Method	Intelligent Fan cooling
Display	LED + LCD
Communication with BMS	RS485
Communication with Cloud	WiFi/4G
Degree of Protection	IP21
Weight(kg)	5.9	6.1
Dimension(WHDmm)	34395275
Mounting Method	Wall Mounted

Manufacturing Excellence

As an established and industry-leading manufacturer of solar photovoltaic products with nearly a decade of experience, we specialize in the precise manufacturing of critical components for solar energy systems. Our factory diligently produces high-performance solar power inverters, advanced AGM/GEL lead-acid battery chargers, robust solar charge controllers, and essential related equipment. Engineered for excellence, Sunchonglic products deliver exceptional reliability and longevity, ensuring optimal performance for your solar investments.

Production Process

Frequently Asked Questions

Q1. Are you the factory manufacturer?

We are doing the Solar Energy Photovoltaic Products for over 20 years. We are the original manufacturer and developer of advanced Solar Energy Photovoltaic Product, including hybrid solar inverter, power inverter, battery chargers, solar controller, and solar system, etc.

Q2. How to select a suitable product?

Tell us your demand, we will recommend a suitable one to you.

Q3. What is your payment methods?

We accept T/T, Trade Assurance, etc.

Q4. What's the price terms can you offer for us?

We can accept EXW, FOB, CIF and so on.

Q5. Where is your main market for your products?

Most of our Sunchonglic brand products are exported to Southeast Asia, Africa and Mid East etc.

Our products are widely recognized and trusted by our clients and can meet continuously changing economic and social needs. We would sincerely welcome new and old customers from over the world to visit and contact us for future business relationships and mutual success!
